24SSM6442EC Series Closed-Loop Servo Hybrid Stepper Motor with Encoder

24SSM6442EC Series Closed-Loop Servo Hybrid Stepper Motor with Encoder

Overview Product Description Baolong's closed-loop servo hybrid stepper motor, attached the encoder with the motor shaft


Basic Info
Model NO. 24SSM6442EC Series
Type Servo Hb
Certification ISO9001, CE
Brand Baolong
Motor Frame NEMA 24
Rated Voltage 1.89 VDC
Phase Current 4.2 A
Holding Torque 1.6 N.m
Motor Length 56 mm
Transport Package Carton with Inner Foam Box; Pallet
Specification CE, Rohs, SGS
Trademark BAOLONG
Origin Jiangsu Changzhou
HS Code 8501310000
Production Capacity 1200000 PCS/Year
Product Description

Baolong's closed-loop servo hybrid stepper motor, attached the encoder with the motor shaft can feedback the motor rotor movement then correct the movement error. It moves with

High precision;High speed;Multi-mode control; High response large torque;Smooth operation;Low noise;Energy-efficient with compact structure.

24SSM6442EC Series Closed-Loop Servo Hybrid Stepper Motor with Encoder

Product Parameters
Phase: 2
Rated Voltage (VDC): 1.89 V
Phase Current (A): 4.2 A
Phase Resistance (ohm): 0.45 (ohm)
Phase Inductance (mH): 1.2 mH
Holding Torque (N.m): 1.6 N.m
Rotor Inertia (g.cm2): 320 g.cm2
Motor Length (mm): 56 mm
Motor Weight (Kg): 0.88 Kg


Our Advantages


Company Profile

Changzhou Baolong Motor , established in 2004, is a high-tech enterprise, which is engaged in the development, production and selling kinds of micro motor and motion control systems.Using high-quality materials, sophisticated manufacturing process and strict quality management our product line includes almost all kinds of high-quality motors, such as hybrid stepper motors, close-loop stepper motors, brushless DC motors, servo motors, etc. Our company is one of the leading manufacturers in domestic and international market, and our products are at the same level of international famous-brand ones. Our products are widely used in computer peripheral devices, communications, stage lighting, textiles, packaging, printing, medical equipment, sewing machines, and other industrial automation systems.Our company is rich in technical experience, we use advanced production process and testing equipment, and obeys advanced quality management requirements in production, such as ISO9001: 2008, 6 Sigma. Besides, our company also has obtained the CE certificate, and all of our products are RoHS compliant.With the spirit of "product innovation, high quality, excellent service", our company will continuously focus on micro motor industry, and provide more high-quality products and more professional service for our clients. We try our best to win the client' S trust by our high-quality products, excellent service and reasonable prices. We are becoming the leader of the micro motor industry.


1) We can accept EXW, FOB
2) Payment must be made before shipment.3) Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility.

1) We only ship to your confirmed address. Please make sure your shipping address is correct before purchase.2) Most orders will be shipped out within 3-7 working days upon payment confirmation.3) Shipping normally takes 7-25 working days. Most of the items will delivery in 2 weeks, while there will be a delay for something we cannot control (such as the bad weather). If it happens, just contact us, we will help you check and resolve any problem.3) Please check the package upon receipt, if there are some damages, please contact us immediately.
Feedback & Refund 1) Feedback is important to us, if you have any problem with our products, please contact us, our technician will give you useful advises. 2) When you have the parcel and not satisfied with the goods or it is other problem, please tell us immediately, and provide us a photo showing the detail. 3) Any reason requiring for all refund. Items must be in original condition and no physical damage. Buyer responsible for all shipping cost.

If you need more information, please contact with us. We will attach great importance to your any problems.Hope we could establish a long-term effective cooperation.
